hot selling 20kw wind generator for home

hot selling 20kw wind generator for home

hot selling 20kw wind generator for home
MODEL: H9.0-20kw
SIZE:
PACKAGE:

Detailed Product Description


20KW wind turbine for home
1.high efficiency
2.CE proved+7patents
3.NO MOQ+wholesale price
4.professional factory



20kw19



20KW wind turbine for home



Features of hummer 20KW wind turbines :

1. SCF supercritical generator technology, generator weigh only 496kg, generation efficiency over 0.87.

 2. Quality parts use SKF bearings and Siemens PLC control system and so on

 3. Sine wave output, drive 6kw pump, 20kw appliances etc.

 4. With protection functions of electronic yawing, electromagnetic break and dump load, even optional mechanical braking protection.

 5. Connect with 6kw solar panels to make up the wind solar hybrid system.

 6. High cost performance.


Application of Model H9.0-20000W
It can drive air-condition ( ≤20 horsepower), 6kw water pump or other resistive appliances (≤20KW).
Well used in:
 Housing and factory and farm
 Telecommunication Station
 TV Transfer Station
 Monitoring Station (military, hydrology, observatory)
 Water-pumping Station
 shipping

Main technical parameter

Rated power(W)
20000
Maximum output power(W)
28000
Charging voltage (V)
DC 240
Blade quantity
3
Rotor blade material
GRP
Rotor blade diameter (ft.)
30  (9.0m)
Start-up wind speed (mph)
7    (3.0m/s)
Rated wind speed (mph)
26  (11.5m/s)
Rated rotating rate (r/min)
180
Wind energy utilizing ratio (Cp)
0.40
Generator output
Frequency conversion AC
Rated charging current (A)
83.3
The maximum charging current (in a short time) (A)
120
Output AC frequency (Hz)
0~320
Generator efficiency
>0.87
Free standing tower diameter (in.)
Ø41.3*Ø29.5 (1050*750mm)
 (2 segment)
Tower height (ft.)
52  (16m)
The weight of generator(lb)
1093  (496kg)
Suggested Battery (Ah)
800/1000
