Front Generator Wind Turbine

Detailed Product Description

wind energy turbine
1.CE proved+7 patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professional factory

 Hummer 2kw wind energy turbine gives you a clear look how small Hummer wind generator is ,which is able to be placed inside nose cone .Though very small , compared with traditional turbine ,its stronger power making ability has won Hummer's reputation in market .Refined material ,strong structure and mature techniques ensure its toughness in wild filed .



  Due to its small size and light weight ,thus easy to carry ,it is a favor to people who often travel ,places that do not require high power supply ,like observation site ,military post and TV transimission station .



 The main technical of 2kw wind energy turbine is :

Rated power(W)	2000
Maximum output powerW	3200
Charging voltage (V)	DC 120
Blade quantity	3
Rotor blade material	GRP
Rotor blade diameterm	3.8
Start-up wind speed (m/s)	3.0
Rated wind speed (m/s)	9.0
Rated rotating rate (r/min)	450
Wind energy utilizing ratio (Cp)	0.45
Generator output	Single-phase frequency conversion AC
Rated charging current (A)	15
The maximum charging current (in a short time )(A)	28
Output AC frequency (Hz)	0~370
Generator efficiency	>0.8
Tower diameter(mm)	114*2000*5 (5pcs)
Tower height(m)	10
The weight of generator(kg)	25
Battery 12V 150Ah/200Ah	10pcs
