1000w wind generator in the USA






Detailed Product Description


1kw wind power generator
1. CE certification+ 7 patents
2. high power efficiency
3. skf bearing
4. easy to install


1kw household wind power generator



With 7 hummer patented technologies and introducing some special materials, H3.1-1000W wind generator with a weight of 15kg. Due to its smallness and lightness, H3.1-1000W wind generator can swiftly start up at low wind speed (3m/s ), and its  power-making ability is stronger than traditional one, the rated output of it is 1000W, and max output is 2000W.



Application of H3.1-1000W wind generator
Well used in:
Housing
Telecommunications Station

TV Transfer Station
Monitoring Station (military, hydrology, observatory)
Water-pumping Station



technical parameters;

H3.1-1000W wind generator in the USA Specifications
Configuration 3 Blades, Horizontal axis, Upwind
Rotor Diameter Ф3.1 m / 10.2 ft
Swept Area 7.55 m2 / 81.3 ft2
Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Rated Power 1 kW @ 10m/s / 22.4 mph
Maximum Output Power 1.2 kW @ 20m/s / 44.7 mph
Battery Bank Voltage 60 Vdc
System Output Voltage 110/220 Vac
Cut-in Wind Speed 3 m/s / 6.7 mph
Rated rotating rate 500 r/min
Working Wind Speed 3-25 m/s / 6.7-82.1  mph
Survival Wind Speed 50 m/s / 164 mph
Alternator Permanent magnet alternator, SCF technology
Alternator Weight 15 kg / 33.1 lbs
Generator Efficiency >0.80
Wind Energy Utilizing Ratio 0.45 Cp
Energy monitoring & User control LED display
Gearbox None, Direct drive with front generator design
Over Speed Regulation Passive furling tail design
Shutting Down Method Manual & Automatic electromagnetism Braking
Warranty 2 years for generator and 1 year for other parts
