2KW Wind generator



  • Products Visitors:4892
  • Product Name:2KW Wind generator
  • Package:0.871 CBM, 7 Packages
  • Size:3.8m wind blades, 10m guyed tower
  • Model:H3.8-2KW



1.Feature:

A.H3.8-2000W's yaw shaft is made of refined steel, tail pole is made of strong manganese steel, and tail wing is made of steel. These refined and high quality materials ensure reliable deflection for protection.16m is the ideal distance between two wind turbines.



B.Application of Model H3.8-2000W  wind turbine: it can drive air-condition (2 horsepower), 800W water pump or other electrical appliances (≤2KW).



C.2kw wind turbine is well used in:

Housing,Telecommunication, StationTV Transfer Station,Monitoring Station (military, hydrology, observatory) and  Water-pumping Station



3.Parameters:

H3.8-2000W Wind generator Specifications
Configuration 3 Blades, Horizontal axis, Upwind
Rotor Diameter Ф3.8 m / 12.5 ft
Swept Area 11.35 m2 / 122.2 ft2
Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Rated Power 2 kW @ 11m/s / 24.6 mph
Maximum Output Power 2.2 kW @ 20m/s / 44.7 mph
Battery Bank Voltage 120 Vdc
System Output Voltage 110/220 Vac
Cut-in Wind Speed 3 m/s / 6.7 mph
Rated rotating rate 450 r/min
Working Wind Speed 3-25 m/s / 6.7-82.2  mph
Survival Wind Speed 50 m/s / 164 mph
Alternator Permanent magnet alternator, SCF technology
Alternator Weight 25 kg / 55.1 lbs
Generator Efficiency >0.80
Wind Energy Utilizing Ratio 0.45 Cp
Energy monitoring & User control LED display
Gearbox None, Direct drive with front generator design
Over Speed Regulation Passive furling tail design
Shutting Down Method Manual & Automatic electromagnetism Braking
Warranty 2 years for generator and 1 year for other parts



3.Curve

2KW Wind Generator Power Curve
