Front Generator Wind Turbine

Detailed Product Description

High efficiency 2kw wind generator
1.patent technology about generator.
2.top quality with reasonable price.

 High efficiency 2kw wind generator

H3.8-2000W Specifications
Configuration	3 Blades, Horizontal axis, Upwind
Rotor Diameter	Ф3.8 m / 12.5 ft
Swept Area	11.35 m2 / 122.2 ft2
Direction of Rotation	Clockwise looking upwind
Blade Material	Fiberglass reinforced composite
Rated Power	2 kW @ 11m/s / 24.6 mph
Maximum Output Power	2.2 kW @ 20m/s / 44.7 mph
Battery Bank Voltage	120 Vdc
System Output Voltage	110/220 Vac
Cut-in Wind Speed	3 m/s / 6.7 mph
Rated rotating rate	450 r/min
Working Wind Speed	3-25 m/s / 6.7-82.2  mph
Survival Wind Speed	50 m/s / 164 mph
Alternator	Permanent magnet alternator, SCF technology
Alternator Weight	25 kg / 55.1 lbs
Generator Efficiency	>0.80
Wind Energy Utilizing Ratio	0.45 Cp
Energy monitoring & User control	LED display
Gearbox	None, Direct drive with front generator design
Over Speed Regulation	Passive furling tail design
Shutting Down Method	Manual & Automatic electromagnetism Braking
Warranty	2 years for generator and 1 year for other parts



1. generator located inside nose cone to radiate heat easily, with generator itself extremely light and small, low in noise.

2. yaw shaft with the slip ring to ensure the rotation at 360 circulation.



3. tail ple and tial wing connecting with the body of wind turbine through SKF ball bearing, more endurable and strong.



4. tower made of galvanised steel anti acid proof and salt proof.



5. 3 in 1 inverter integrating the functions of battery charging, inverting, controlling. diversion lights  included, a pare terminal of solar panel on the back.
