3kw wind turbine generator in Singapore


Detailed Product Description

wind power generator
1.high efficiency
2.CE proved+7patents
3.NO MOQ+wholesale price

4.professional factory

wind power generator


Features of hummer 3000W wind turbines:

     1. SCF supercritical generator technology, generator weigh only 60kg, generation efficiency over 0.80.

     2. Quality parts use SKF bearings and Siemens PLC control system and so on

     3. Sine wave output, drive 1200w pump, 3kw appliances etc.

     4. Connect with 900w solar panels to make up the wind solar hybrid system.

     5. Generate 1kw power at 9m / s

     6. High cost performance


Application of Model H4.6-3000W

It can drive air-condition (3 to 3.5 horsepower), 1000W water pump or other resistive appliances (≤3KW).
Well used in:
 Telecommunication Station
 TV Transfer Station
 Monitoring Station (military, hydrology, observatory)
 Water-pumping Station


The specification for 3kw wind power generator is :

H4.6-3KW wind turbine generator in Singapore Specifications
Configuration 3 Blades, Horizontal axis, Upwind
Rotor Diameter Ф4.9 m / 16.1 ft
Swept Area 18.86 m2 / 203.0 ft2
Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Rated Power 3 kW @ 10m/s / 22.4 mph
Maximum Output Power 3.3 kW @ 20m/s / 44.7 mph
Battery Bank Voltage 180 Vdc
System Output Voltage 110/220 Vac
Cut-in Wind Speed 3 m/s / 6.7 mph
Rated rotating rate 265 r/min
Working Wind Speed 3-25 m/s / 6.7-82.3  mph
Survival Wind Speed 50 m/s / 164 mph
Alternator Permanent magnet alternator, SCF technology
Alternator Weight 72 kg / 158.7 lbs
Generator Efficiency >0.80
Wind Energy Utilizing Ratio 0.40 Cp
Energy monitoring & User control Siemens PLC controller with touch screen
Gearbox None, Direct drive with front generator design
Over Speed Regulation Auto Yawing
Shutting Down Method Manual & Automatic electromagnetism Braking
Warranty 2 years for generator and 1 year for other parts
