1.Features:
A.sine wave controller system . Our controller system are three-in -one
design with the functions of charging ,inverting and unloading .
B.Hummer H3.1-1kw grid-tied system
is well used in Housing ,ships ,telecommunications station ,TV transfer station ,Monitoring station (military ,hydrology ,observatory )water-pumping etc .
C.And it can connected within 500w solar panel with the help of hummer solar-wind hybrid controlling system .
2.Parameters:
H3.1-1000W grid-tied wind generator system Specifications | |
Configuration | 3 Blades, Horizontal axis, Upwind |
Rotor Diameter | Ф3.1 m / 10.2 ft |
Swept Area | 7.55 m2 / 81.3 ft2 |
Direction of Rotation | Clockwise looking upwind |
Blade Material | Fiberglass reinforced composite |
Rated Power | 1 kW @ 10m/s / 22.4 mph |
Maximum Output Power | 1.2 kW @ 20m/s / 44.7 mph |
Battery Bank Voltage | 60 Vdc |
System Output Voltage | 110/220 Vac |
Cut-in Wind Speed | 3 m/s / 6.7 mph |
Rated rotating rate | 500 r/min |
Working Wind Speed | 3-25 m/s / 6.7-82.1 mph |
Survival Wind Speed | 50 m/s / 164 mph |
Alternator | Permanent magnet alternator, SCF technology |
Alternator Weight | 15 kg / 33.1 lbs |
Generator Efficiency | >0.80 |
Wind Energy Utilizing Ratio | 0.45 Cp |
Energy monitoring & User control | LED display |
Gearbox | None, Direct drive with front generator design |
Over Speed Regulation | Passive furling tail design |
Shutting Down Method | Manual & Automatic electromagnetism Braking |
Warranty | 2 years for generator and 1 year for other parts |
3.Curve
4.Working principles
