wind generator






Detailed Product Description


wind power generator
1.CE proved+7 patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professtional factory

Main technical data



Rated power (W)
2000
Maximum output power (W)
3200
Charging voltage (V)
DC 120
Blade quantity
3
Rotor blade material
GRP
Rotor blade diameter (ft.)
12  (3.8m)
Start-up wind speed (mph)
7    (3.0m/s)
Rated wind speed (mph)
20  (9.0m/s)
Rated rotating rate (r/min)
450
Wind energy utilizing ratio (Cp)
0.45
Generator output
Frequency conversion AC
Rated charging current (A)
16.7
The maximum charging current (in a short time )(A)
28
Output AC frequency (Hz)
0~370
Generator efficiency
>0.8
Tower diameter (in.)
ø4.5*78.7*0.2 (ø114*2000*4 mm) (5pcs)
Tower height (ft.)
33  (10m)
The weight of generator (lb)
55  (25kg)
Suggested Battery (Ah)
150/200
