wind generators



  • Products Visitors:2867
  • Product Name:wind generators
  • Package:0.283 CBM, 3 Packages
  • Size:2.7m wind blades, 6m guyed tower
  • Model:H2.7-500W



Detailed Product Description

wind turbine for home
1.CE proved+7patents
2.high efficiency+small size
3.NO MOQ+wholesale price
4.professional factory


 wind turbine for home

 Features of hummer 500W wind turbines:

1. SCF supercritical generator technology, generator weight only 6.5 kg, generator efficiency over 0.78.

2. Quality parts use SKF bearings and so on

3. Sine wave output, drive water pump < 370w, refrigerator <130L etc.

4. High cost performance

5. Low running noise

6. Connect with 300W solar panels to make up the wind-solar hybrid system.



Application of Model H2.7-500W wind turbine

It can drive color TV, refrigerator<=130L, pump<=370W or other resistive appliances <500W.

Well used in:

Housing, office, farm and factory

Telecommunications Station

TV Transfer Station

Monitoring Station-military, hydrology, observatory

Water-pumping Station

Main technical data

H2.7-500W Wind Generators Specifications
Configuration 3 Blades, Horizontal axis, Upwind
Rotor Diameter Ф2.7 m / 8.9 feet
Swept Area 5.73 m2 / 61.7 ft2
Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Rated Power 500W @ 11m/s / 24.6 mph
Maximum Output Power 570W @  20m/s / 44.7 mph
Battery Bank Voltage 24 Vdc
System Output Voltage 110/220 Vac
Cut-in Wind Speed 3 m/s / 6.7 mph
Rated rotating rate 600 r/min
Working Wind Speed 3-25 m/s / 6.7-82.0  mph
Survival Wind Speed 50 m/s / 164 mph
Alternator Permanent magnet alternator, SCF technology
Alternator Weight 6.5 kg / 14.3 lbs
Generator Efficiency >0.78
Wind Energy Utilizing Ratio 0.48 Cp
Energy monitoring & User control LED display
Gearbox None, Direct drive with front generator design
Over Speed Regulation Passive furling tail design
Shutting Down Method Manual & Automatic electromagnetism Braking
Warranty 2 years for generator and 1 year for other parts
