wind power turbine



  • Products Visitors:2665
  • Product Name:wind power turbine
  • Package:8.595 CBM, 8 Packages
  • Size:15m free standing tower
  • Model:H8.0-10kw



Detailed Product Description


10KW wind power turbine 2011
1.CE proved+7 patents
2.high efficiency
3.NO MO+wholesale price
4.professional factory




10KW wind power turbine 2011


Featurers:

Small & light structure ,the generator is installed inside the nose cone which can help for heat dispersion and reduce the wind resistance .

Blades designed according structure and aircraft technology

Generator built with permanent magnetic materials which have 4 patented technologies

Advanced controlling system ,can be connected to the local grid directly or for off-grid usage .

Special anti-corrosion treatment of the parts

Specification and performance of 10kw wind power turbine :

H8.0-10KW wind power turbine Specifications
Configuration 3 Blades, Horizontal axis, Upwind
Rotor Diameter Ф8.0 m / 26.2 ft
Swept Area 50.27 m2 / 541.1 ft2
Direction of Rotation Clockwise looking upwind
Blade Material Fiberglass reinforced composite
Rated Power 10 kW @ 11m/s / 24.6 mph
Maximum Output Power 11 kW @ 20m/s / 44.7 mph
Battery Bank Voltage 240 Vdc
System Output Voltage 110/220/380 Vac
Cut-in Wind Speed 3 m/s / 6.7 mph
Rated rotating rate 200 r/min
Working Wind Speed 3-25 m/s / 6.7-82.5  mph
Survival Wind Speed 50 m/s / 164 mph
Alternator Permanent magnet alternator, SCF technology
Alternator Weight 287 kg / 632.7 lbs
Generator Efficiency >0.85
Wind Energy Utilizing Ratio 0.40 Cp
Energy monitoring & User control Siemens PLC controller with touch screen
Gearbox None, Direct drive with front generator design
Over Speed Regulation Auto Yawing & Hydraulic Braking
Shutting Down Method Manual & Automatic electromagnetism Braking & Hydraulic Braking
Warranty 2 years for generator and 1 year for other parts



Parts are included of 10kw wind power turbine :Generator ,rotor blades, nose cone ,hub,protect cover ,yaw shaft ,controlling system ,inverter and unloader . The tower and tower kits are optional .



For more details or demands , pls to do hesitate to contact with us , we will provide the best solutions and right products for you .
