wind generator equipment
Main technical parameter
Rated power (W) | 30000 |
Maximum output power (W) | 45000 |
Charging voltage (V) | DC 360 |
Blade quantity | 3 |
Rotor blade material | GRP |
Rotor blade diameter (ft.) | 33 (10.0m) |
Start-up wind speed (mph) | 6 (2.5m/s) |
Rated wind speed (mph) | 25 (11.0m/s) |
Rated rotating rate (r/min) | 160 |
Wind energy utilizing ratio (Cp) | 0.42 |
Generator output | Frequency conversion AC |
Rated charging current (A) | 83 |
The maximum charging current (in a short time ) (A) | 125 |
Output AC frequency (Hz) | 0~400 |
Generator efficiency | >0.92 |
Free standing tower diameter (in.) | Φ47.2*Ø18.7 (Ø1200*Φ475mm) |
Tower height (ft.) | 59 (18m) |
The weight of generator (lb) | 1764 (800kg) |
Suggested Battery (Ah) | 600/1000 |
