wind generator equipment
As a professional manufacturer of small-sized wind generator equipment,we can offer products from 500w-20kw wind turbine generator .
They have the great features of high power efficiency ;low energy comsumption by the wind
turbine generator itself ;low start-up wind speed with the patented technology ;long life design
with easily installation and maintenance .
5kw wind generator equipment is well used in :
housing ;ships ;remote rural areas;telecommunication stations ,monitoring stations, water-pumping etc .
The main technical datas of Hummer H6.4-5000w wind generator equipment is as bellowing :
Rated power(W) |
5000 |
Maximum output powerW |
7500 |
Charging voltage (V) |
DC 240 |
Blade quantity |
3 |
Rotor blade material |
GRP |
Rotor blade diameterm |
6.4 |
Start-up wind speed (m/s) |
2.5 |
Rated wind speed (m/s) |
10.0 |
Rated rotating rate (r/min) |
240 |
Wind energy utilizing ratio (Cp) |
0.4 |
Generator output |
Single-phase frequency conversion AC |
Rated charging current (A) |
20 |
The maximum charging current (in a short time )(A) |
32 |
Output AC frequency (Hz) |
0~360 |
Generator efficiency |
>0.8 |
Free standing tower diameter(mm) |
495*185*12000 (2pcs) |
Guy tower diameter(mm) |
220*3000*6 (4pcs) |
Tower height(m) |
12 |
The weight of generator(kg) |
147 |
Battery 12V 150Ah/200Ah |
20pcs |
